- With CY7C68013A 56 chip
- Enhanced 51 core, 16 kilobytes of program data area, the 48MHz frequency low power consumption.
- Up to 480Mbps, high-speed transmission protocol standards along the USB2.0 specification, backward compatible with USB 1.1
- 128Kbit (24LC128) in the board to the large capacity of the program memory (EEPROM) is used for storage of VID / PID and the USB firmware.
- You can meet in CY7C68013A program space.
Product description
CY7C68013A-56 chip: low-power version of the enhanced 51-core, 16KB program data areas, clocked at 48Mhz,
480Mbps high-speed transmission protocol standards, in line with USB2.0 specification, backward compatible with USB1.1.
Firmware, EEPROM: complete the program in-system programming directly with a USB cable to download the firmware,
on-board to provide 16K (24LC128) a large program memory (EEPROM), used as storage VID / PID and the USB firmware, the program space to meet the CY7C68013A need.
All GPIO After 2.54mm standard pin lead out, the great convenience learners expand their own design.
With corresponding firmware can be achieved through the core board logic analyzer function.
Provide the PDF principle diagram and related source
Download link:
http://download.haljia.com/download/Board/CY7C68013AModule/SDK.rar
Packing List:
1*CY7C68013A-56 EZ-USB FX2LP USB2.0 Develope Board Module Logic Analyzer EEPROM
