- The volume is ultra-small
- Serial to WiFi
- Wireless transmission
- Long-range ultra-low power consumption
- High temperature, up to 125 Degrees Celsius fully compatible with ESP8266, the source can be used to transplant.
Product description
Colour:black
Material:metal
N SOC characteristics
Built-in Tensilica L106 ultra low power 32-bit microprocessor, clocked at 80MHz and 160MHz support RTOS
Built-in TCP / IP protocol stack
Built-in 1-channel 10-bit high-precision ADC
L Peripheral interface HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
L Deep sleep hold current is 10uA and shutdown current is less than 5uA
Within 2 ms wake up, connect and pass the packet
L standby power consumption less than 1.0mW (DTIM3)
Built-in 1M bytes SPI Flash
N Wi-Fi features
Supports 802.11 b / g / n / e / i
L Support Station, SoftAP, SoftAP + STA mode
L support for Wi-Fi Direct (P2P)
L Support hardware acceleration of CCMP (CBC-MAC, counter mode), TKIP (MIC, RC4), WAPI (SMS4), WEP (RC4), CRC
P2P discovery, P2P GO mode / GC mode and P2P power management
L WPA / PA2 PSK and WPS
L 802.11n (2.4 GHz)
L 802.1h / RFC1042 frame encapsulation
L seamless roaming support
L support AT remote upgrade and cloud OTA upgrade
L Support for Smart Config features (including Android and iOS devices)
Packing List:
1 x Wireless WiFi control module
