- NRF24L01 is a single chip radio transceiver for the world wide 2.4 - 2.5 GHz ISM band.
- The transceiver consists of a fully integrated frequency synthesizer, a power amplifier, a crystal oscillator, a demodulator, modulator and enhanced shockburst protocol engine.
- Output power, frequency channels, and protocol setup are easily.
- Programmable through a SPI interface. Current consumption is very low, only 9.0mA at an output power of -6dBm and 12.3mA in RX mode.
- Built-in Power Down and Standby modes makes power saving easily realizable.
This item is a pack of 10pcs NRF24L01+ 2.4GHz wireless traceiver modules, maximum operating speeds up to 2Mbps, GFSK modulation efficiency, anti-interference ability, particularly suitable for industrial control applicatio. 125 communicatio channels, multi-point communication and frequency hopping to meet the communication needs. Built-in hardware CRC error detection, multipoint communication address control.
Available software to set the address, only received local Address when output data(Provide interrupt itruction), can be directly connected to a variety of microcontrolle, Software programming is very convenient.
Support 6 Data channels of data reception.
Standard DIP Pitch Interface for embedded applicatio.
Size: 34mm X 17mm X 1mm.
Notice: Traceive integrated module , tramit or receive can not be simultaneously by one module.
Packing List:
1 x NRF24L01+ 2.4GHz Enhanced Wireless Transceiver Modules
