- Portable electronic weight sensor
- Rated load: 1Kg
- For DIY Arduino etc.
- Recommended operating voltage: 3 ~ 12 V DC
- Protection class: IP65
Specification:
Rated load: 1kg
Rated output: 1.0mV / V + -0.15mV / V
Zero output: ± 0.1mV / V
Creep: 0.03% F.S./30min
Input end: red + , black-
Output end: green + , white-
Recommended operating voltage: 3 ~ 12 V DC
Maximum operating voltage: 15 V DC
Input impedance: 1115 ± 10% R
Output impedance: 1000 ± 10% R
Protection class: IP65
Overall size approx. 8 x 1.3 x 1.3 cm
Cable size: 0.8 x 20 cm (diameter x length)
Material: aluminum alloy
Package Inculded:
1 x weighing sensor (cable: 20 cm)
