- Red color
- Power supply: 9-12V DC input
- Waveforms: square, sine and triangle
- Impedance: 600 ohms + 10%
- Frequency: 1Hz - 1MHz
Specifications:
SINE WAVE
Amplitude: 0-3V at 9V DC Input
Distortion: Less than 1% (at 1KHz)
Flatness: +0.05dB 1Hz - 100kHz
SQUARE WAVE
Amplitude: 8V (no load) at 9V DC Input
Rise Time: Less than 50ns (at 1KHz)
Fall Time: Less than 30ns (at 1KHz)
Symmetry: Less than 5% (at 1KHz)
TRIANGLE WAVE
Amplitude: 0-3V at 9V DC Input
Linearity: Less than 1% (up to 100KHz) 10mA
Package Inculded:
1 x XR2206 Function Signal Generator Module Kit
